Manage your VC conferencing needs across a large number of distributed sites. Enjoy smooth, seamless multi-point conferences with high-quality voice, HD or SD video with simultaneous PC data sharing.
PCS-VCS Server Software helps organisations communicate more effectively, linking dedicated videoconferencing systems at as many as 500 remote sites (depending on license).
It’s ideal for use with the Sony PCS-XG80, PCS-XG55, PCS-XL55, PCS-XA80 and PCS-XA55 videoconferencing systems. Remote workers can join virtual meetings from anywhere there’s a broadband IP connection available, requiring only PCS-EP endpoint software on their PC.
Easy expansion requires just a simple license purchase to cover up to 500 sites.
Software requires installation on a server (not included).
W przypadku pytań, proszę o kontakt:
GSM. 504 58 64 88
tel. 22 490 31 43
|Communication protocol||H.323 (ITU-T)|
|Video codec format||H.261, H.263, H.264|
|Audio codec format||G.711, G.722|
|Video resolution - HD||1080i (full screen Video Switch only), 720p, W432p, WCIF, 4CIF, CIF, QCIF|
|Video resolution - SD||4CIF, CIF, QCIF|
|Video aspect ratio - HD||4:3 or 16:9|
|Video aspect ratio - SD||4:3|
|H.239 content sharing||Codec: H.263, H.264*1
|Video mode||Full screen (Video switching mode)
Split screen (CPn mode) max. 16 split screen display
Highlight speaker and display terminal name
|Video switching mode||Voice switch, Time switch, Manual switch (Chairman, Selected user)|
|Audio mixing||Audio mix of 5 loudest speakers as default
AGC (Automatic Gain Control)
|Meeting type||Normal meeting
All users have equal authority of speaker start/stop, etc.
Chairman control meeting
Chairman has authority of speaker start/stop, changing display
|Access method to meeting||Calling out from endpoint (H.323 alias, E.164 number)
Calling out endpoint from MCU
Leaving by user operation
Leaving by administrator’s or chairman’s operation
|Access control||Setting access control for each meetings
Limit by H.332 alias, E.164 number, IP address
Setting for maximum connected users
|Bandwidth limitation||Max. bandwidth for each meeting and each user, Max. total bandwidth setting
Max. bandwidth control method
Static: New endpoint cannot enter when it reaches max. bandwidth
Dynamic: New endpoint can enter when it reaches max.
bandwidth, bandwidth is separate equally by all endpoints
|Meeting scheduling||Always activate
Scheduled (one time, everyday, every week, every month)
Calling out from MCU at reserved starting time
|Number of connected site||Single screen: Max. 500 endpoints
HD CP4 conference: Max. 250 (768kbps) Max.200 (1.5Mbps)
SD CP4 conference: Max. 400 (384kbps)
* CPU: Intel X5680 (3.33 GHz) x 2CPU, Memory: 12Gbyte
|Administrative operation||VCOnline web-based central management|
|Meeting reservation system||Web-based meeting reservation function|
|Shared phone book||Embedded shared phone book server of SONY PCS series|
|Firmware update||Embedded firmware update function of SONY PCS-XG80/XG55/ XL55/XA80/XA55|
|*1||Available with upgrade|
